PT Style Push-On Bolt Retainers
Shaft & Bolt Retainers
PT Style Push-ons are temporary stamped retainers that hold pre-inserted bolts in place until they reach final assembly. These bolt retainers may be used alone for load-carrying in light duty assemblies or may be used on top of ordinary nuts to assure tightness of high stress assemblies. They offer an impressive cost savings of alternative fasteners in their initial cost, assembly time, weight and space.
Item # |
Item Name |
Screw Size |
Material Thickness (Decimal) |
Part Diameter |
---|---|---|---|---|
02P694007-450 /Asset/01789_a_6.jpg | N/A M8 x 1.25 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M8 x 1.25 | Material Thickness (Decimal) N/A 0.360 in | Part Diameter N/A 15.9 mm |
02P694002-03Q /Asset/01789_a_6.jpg | N/A M4 x 0.7 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M4 x 0.7 | Material Thickness (Decimal) N/A 0.250 in | Part Diameter N/A 9.52 mm |
02P800002-01Q /Asset/01789_a_6.jpg | N/A M4 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M4 | Material Thickness (Decimal) N/A 0.250 in | Part Diameter N/A 12.70 mm |
02P694003-01Q /Asset/01789_a_6.jpg | N/A M5 x 0.8 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M5 x 0.8 | Material Thickness (Decimal) N/A 0.3 in | Part Diameter N/A 11.1 mm |
02P694003-99Q /Asset/01789_a_6.jpg | N/A M5 x 0.8 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M5 x 0.8 | Material Thickness (Decimal) N/A 0.3 in | Part Diameter N/A 11.1 mm |
02P694003-137Q /Asset/01789_a_6.jpg | N/A M5 x 0.8 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M5 x 0.8 | Material Thickness (Decimal) N/A 0.3 in | Part Diameter N/A 11.1 mm |
02P694003-03Q /Asset/01789_a_6.jpg | N/A M5 x 0.8 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M5 x 0.8 | Material Thickness (Decimal) N/A 0.3 in | Part Diameter N/A 11.1 mm |
02P694004-01Q /Asset/01789_a_6.jpg | N/A M6 x 1.0 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M6 x 1.0 | Material Thickness (Decimal) N/A 0.250 in | Part Diameter N/A 12.70 mm |
02P694004-132Q /Asset/01789_a_6.jpg | N/A M6 x 1.0 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M6 x 1.0 | Material Thickness (Decimal) N/A 0.250 in | Part Diameter N/A 12.70 mm |
02P800004-09Q /Asset/01789_a_6.jpg | N/A M6 x 1.0 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M6 x 1.0 | Material Thickness (Decimal) N/A 0.250 in | Part Diameter N/A 12.70 mm |
02P694004-137Q /Asset/01789_a_6.jpg | N/A M6 x 1.0 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M6 x 1.0 | Material Thickness (Decimal) N/A 0.250 in | Part Diameter N/A 12.70 mm |
02P694004-163 /Asset/01789_a_6.jpg | N/A M6 x 1.0 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M6 x 1.0 | Material Thickness (Decimal) N/A 0.250 in | Part Diameter N/A 12.70 mm |
02P694004-04 /Asset/01789_a_6.jpg | N/A M6 x 1.0 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M6 x 1.0 | Material Thickness (Decimal) N/A 0.250 in | Part Diameter N/A 12.70 mm |
02P694004-03 /Asset/01789_a_6.jpg | N/A M6 x 1.0 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M6 x 1.0 | Material Thickness (Decimal) N/A 0.250 in | Part Diameter N/A 12.70 mm |
02P694004-FD7 /Asset/01789_a_6.jpg | N/A M6 x 1.0 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M6 x 1.0 | Material Thickness (Decimal) N/A 0.250 in | Part Diameter N/A 12.70 mm |
02P800104-01 /Asset/01789_a_6.jpg | N/A M6 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M6 | Material Thickness (Decimal) N/A 0.250 in | Part Diameter N/A 15.80 mm |
02P694005-01 /Asset/01789_a_6.jpg | N/A M6 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M6 | Material Thickness (Decimal) N/A 0.250 in | Part Diameter N/A 16.90 mm |
02P694005-04Q /Asset/01789_a_6.jpg | N/A M6 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M6 | Material Thickness (Decimal) N/A 0.250 in | Part Diameter N/A 16.90 mm |
02P694005-03 /Asset/01789_a_6.jpg | N/A M6 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M6 | Material Thickness (Decimal) N/A 0.250 in | Part Diameter N/A 16.90 mm |
02P694005-119 /Asset/01789_a_6.jpg | N/A M6 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M6 | Material Thickness (Decimal) N/A 0.250 in | Part Diameter N/A 16.90 mm |
02P689104-137Q /Asset/01789_a_6.jpg | N/A M8 x 1.25 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M8 x 1.25 | Material Thickness (Decimal) N/A 0.360 in | Part Diameter N/A 15.9 mm |
02P689104-454 /Asset/01789_a_6.jpg | N/A M8 x 1.25 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M8 x 1.25 | Material Thickness (Decimal) N/A 0.360 in | Part Diameter N/A 15.9 mm |
02P694007-03Q /Asset/01789_a_6.jpg | N/A M8 x 1.25 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M8 x 1.25 | Material Thickness (Decimal) N/A 0.360 in | Part Diameter N/A 15.9 mm |
02P689104-09Q /Asset/01789_a_6.jpg | N/A M8 x 1.25 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M8 x 1.25 | Material Thickness (Decimal) N/A 0.360 in | Part Diameter N/A 15.9 mm |
02P694007-132 /Asset/01789_a_6.jpg | N/A M8 x 1.25 Screw Size PT Style Push-On Bolt Retainer | Screw Size N/A M8 x 1.25 | Material Thickness (Decimal) N/A 0.360 in | Part Diameter N/A 15.9 mm |
