Self-Retaining T-Nut fasteners are bushings with internal threads and a substantial base that combine the functions of a nut and washer. They offer many design advantages and frequently cut weight, labor and cost.
Unit of Measure

Specifications

Fastener Type

 N/A Round Base

Thread Size

 N/A 5/16-18

Prong Length

 N/A 7.50 mm0.296 in

Base Height

 N/A 0.052 in1.30 mm

Collar Length

 N/A 0.375 in9.50 mm

Major Collar Outside Diameter

 N/A 0.369 in9.40 mm

Minimum Collar Outside Diameter

 N/A 0.364 in9.30 mm

Overall Diameter

 N/A 0.875 in22.20 mm

Number of Prongs

 N/A 6

Prong Type

 N/A Claw

Material

 N/A 1013 Low Carbon Steel Strip

Finish

 N/A Cleaned Oiled

Applications

Applications

 N/A Non-Metallic Applications: Self-Retaining T-Nut fasteners are usually driven into holes. They may provide threads and add strength to relatively weak materials. Some T-Nut fasteners for non-metallic applications may be fed and applied automatically.

Features and Benefits

Features and Benefits

 N/A In metal applications, Self-Retaining T-Nut Fasteners are typically spot welded or projection welded with the flange attached to a base plate. They may also be snapped into holes. Either way, they obviate costly tapping and simplify design.
