Sealing Plugs for Unified/Straight Threads protect Unified/Straight-threaded ports and fittings from moisture, dust and damage during production, shipping and storage. The yellow nylon material offers high resistance against hydraulic fluids, solvents, acids and base alkalines.
Unit of Measure

Specifications

Material

 N/A Polyethylene

Color

 N/A Red

Length

 N/A 0.390 in9.9 mm

Flange Outside Diameter

 N/A 1.020 in25.9 mm

To Fit Standard Thread

 N/A 3/4-16

Stem Height

 N/A 0.510 in13.0 mm

Applications

Applications

 N/A Sealing

Features and Benefits

Features and Benefits

 N/A
  • Five complete threads and a sealing lip provide the tight fit for a secure seal
  • Installation and removal by hand or by socket wrench, screwdriver or power tool
  • Sizes to fit 7/16-20 through 1-5/8-12 Unified/Straight Threads

Note

Note

 N/A Sealing Plugs for Unified/Straight Threads are also available with a factory-fit Neoprene Rubber O-Ring when a perfect seal is required.
