Starlock® Push On Fasteners are a precision fastening component designed for applications requiring quick, permanent and efficient means of assembly. The Starlock eliminates costly threading and grooving operations, facilitates rapid assembly, and once fixed in position, provides permanent fixing and gripping. A full range of Inch sizes are available covering shaft diameters from 1/16 inch to 1.00 inch. All Starlocks listed below Include a domed cap.
Unit of Measure
Specifications
Brands |
N/A Starlock® |
Material |
N/A Carbon Spring Steel Stainless Steel |
Material Thickness (Decimal) |
N/A 0.236 mm |
Height |
N/A 0.295 in |
External Diameter |
N/A 1.025 in |
Internal Diameter |
N/A 0.5075 to 0.5175 in |
Number of Legs |
N/A 6 |
Pull Off Force |
N/A 2453 N |
Push on Force |
N/A 589 N |
Shaft Diameter (Fractional) |
N/A 17/32 in |
Shaft Diameter (Decimal) |
N/A 0.5312 in |
